Description

Sku: E12727

Rosemount 644H Temperature Transmitter

Rosemount Part No. 644HFNAJ2M5Q4

Specifications
Input: Dual and single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)
Output Signal: 4-20 mA /HART® protocol, FOUNDATION™ fieldbus protocol, PROFIBUS® PA protocol
Housing: Field mount, DIN A head mount or rail mount
Display/Interface: LCD Display or LCD Display with Local Operator Interface (LOI)
Diagnostics: Basic diagnostics, Hot Backup™ capability, sensor drift alert, thermocouple degradation, min/max tracking
Calibration Options: Transmitter-sensor matching (Callendar-Van Dusen constants), 5-point calibration
Certifications/Approvals: SIL 2/3 certified to IEC 61508 by an independent 3rd party, hazardous location, marine type, see full specs for complete list of certifications.
