Description

Model: 644HAE1J6M5Q4

Rosemount Temperature Transmitter Gage Model 644HAE1J6M5Q4

Rosemount™ 644 Temperature Transmitter

Engineered for versatility, the Rosemount 644 Temperature Transmitter is available with HART®, FOUNDATION™ Fieldbus or PROFIBUS® protocols in head, field or rail mount styles and a variety of enclosure options. By adding a Local Operator Interface (LOI), you can update your transmitter configuration in the field without tools. For diverse application requirements, this transmitter includes diagnostic capabilities, such as Hot Backup™ capability, sensor drift alert and thermocouple degradation.

Input: Dual and single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)
Output: Signal4-20 mA /HART® protocol, FOUNDATION™ fieldbus protocol, PROFIBUS® PA protocol
Housing: Field mount, DIN A head mount or rail mount
Display/Interface: LCD Display or LCD Display with Local Operator Interface (LOI)
Diagnostics: Basic diagnostics, Hot Backup™ capability, sensor drift alert, thermocouple degradation, min/max tracking
Calibration:  OptionsTransmitter-sensor matching (Callendar-Van Dusen constants), 5-point calibration
Certifications/Approvals: SIL 2/3 certified to IEC 61508 by an independent 3rd party, hazardous location, marine type, see full specs for complete list of certifications.
